Features
● Cycled, 9 pairs of sensor, excellent anti-disturbance performance.
● Based on LED bar displayed control panel
● High accuracy detection locating technology,LED indication
● Level setup indication and real-time sensitivity display
● Optional conveying mode after alarm
● Optional automatically restart
● Reliability mechanical frame design,High stable during detection
● Designed for universal AC power supply, switch power supply.
Specifications
| Model | NDC-A |
| Detection method | Magnetic induction |
| Detection sensitivity | 0.8mm steel to small scissors |
| Detection adjustment | 10 steps |
| Detection width | 600mm |
| Alarm method | Buzzer, Lamp |
| Belt speed | 32m/min(50Hz), 40m/min(60Hz) |
| Power souce | AC100-240V 50-60Hz |
| Rated output | Appr.140W |
| Dimension(L*W*H) | 1650mmx1050mmx900mm |
| Weight | Appr.220kg |
Sensitivity
| Height | Detection Sensibility | Remark |
| 100mm | 0.8mm steel to small scissors | Standard type |
| 120mm | 1.0mm steel to small scissors | Option at factory |
| 150mm | 1.2-1.5mm steel to small scissors | Option at factory |
| 200mm | 1.5-2.0mm steel to small scissors | Option at factory |
